Microtek ArtixScan 120tf Reference Manual

Reference: Appendix 131
Professional CMYK Profiles Package
What You Get with Professional CMYK Profiles Package
“Professional CMYK Profiles” was developed for the serious professional, who is
concerned about productivity, quality separations, and color fidelity.
With “Professional CMYK Profiles”, you get six different UCR/GCR settings that
conform to generic CMYK SWOP, Japanese Ink Standard, and Euroscale
standards—Letting you select the best values for your printing conditions.
Any of these combinations give you the control you need to optimize your
separations for your proofing and printing applications, reduce your printing
costs, and minimize ink trapping problems on press.
However, check with your printer as to the optimal UCR/GCR setting to select
for your printing conditions. The following two pages list the settings for the
three standards.
EUROPEAN PRINTING STANDARDS:
Filename Profile Description GCR Maximum TAC
eucmyk02.pf Light GCR 260 UCR CMYK Light 260%
Euro Positive Proofing
eucmyk04.pf Light GCR 280 UCR CMYK Light 280%
Euro Positive Proofing
eucmyk06.pf Light GCR 300 UCR CMYK Light 300%
Euro Positive Proofing
eucmyk08.pf Light GCR 320 UCR CMYK Light 320%
Euro Positive Proofing
eucmyk10.pf Light GCR 340 UCR CMYK Light 340%
Euro Positive Proofing
eucmyk50.pf Light GCR 360 UCR CMYK Light 360%
Euro Positive Proofing

Microtek ArtixScan 120tf Specifications

Power

voltage	AC 90V to 264V, 47-63 Hz

Operating Environment

operating temperature	50° to 95°F (10° to 35°C)
relative humidity	20% to 80%

Scanning Specifications

scanning area	6 x 9 cm Max., 6 x 7 cm, 6 x 6 cm, 6 x 4.5 cm, 25 x 38 mm
resolution optical	4, 000 dpi x 4, 000 dpi
resolution interpolated	16, 000 dpi x 16, 000 dpi

Interfaces

firewire ports	Two
scsi ports	Two
transmission speed firewire	4 Mbytes/s
transmission speed scsi	2 Mbytes/s

Weight and Dimensions

dimensions	19.8" x 10.8" x 5.5" (504 x 274 x 142 mm)
weight	17.6 lb (8 kg)
