Microtek ArtixScan 120tf Reference Manual

80 Microtek ScanWizard Pro TX for Mac & PC
Enable this
check box to
show the
adjustment
effect on the
prescan image
White
Eyedropper for
Dmin settings
Black Eyedropper for
Dmax settings
Eyedropper tools
You can use the Black and White Eyedropper tools (instead of the sliders) to
define the Dmax (darkest tone) and the Dmin (lightest tone) settings,
respectively.
For Mac
Click the Eyedropper tools in the Dynamic Range dialog box. Then move to the
thumbnail image in the dialog box or to the preview image in the Preview
window, and choose your Dmax / Dmin point directly from the image.
For PC
Move the mouse pointer into the prescan image in the Preview window. Notice
that the pointer turns into the Black Eyedropper. To turn the pointer into the
White Eyedropper, press the Alt key. Then choose your Dmax / Dmin point
directly from the image.
• To define the Dmax (darkest tone) setting, use the Black Eyedropper tool.
• To define the Dmin (lightest tone) setting, use the White Eyedropper tool.

Microtek ArtixScan 120tf Specifications

Power

voltage	AC 90V to 264V, 47-63 Hz

Operating Environment

operating temperature	50° to 95°F (10° to 35°C)
relative humidity	20% to 80%

Scanning Specifications

scanning area	6 x 9 cm Max., 6 x 7 cm, 6 x 6 cm, 6 x 4.5 cm, 25 x 38 mm
resolution optical	4, 000 dpi x 4, 000 dpi
resolution interpolated	16, 000 dpi x 16, 000 dpi

Interfaces

firewire ports	Two
scsi ports	Two
transmission speed firewire	4 Mbytes/s
transmission speed scsi	2 Mbytes/s

Weight and Dimensions

dimensions	19.8" x 10.8" x 5.5" (504 x 274 x 142 mm)
weight	17.6 lb (8 kg)
