4-OPERATINGINSTRUCTIONS
Toreleasetheseatbelt,pushthebuttoninthecenterof
thebuckleandseparatethebuckleandmetaleye.
Whenyouaretraininganoperator,besuretheinstruc-
tionalseatbeltisalsosecurelyfastened.
RCPH09FWD037AAJ3
Steeringcolumnadjustment
WARNING
Lossofcontrolhazard!
DONOTmakeseatadjustmentswhilethemachineisinmotion.Allseatadjustmentshouldbemade
withthemachinestationaryandtheparkingbrakeapplied.
Failuretocomplycouldresultindeathorseriousinjury.
W0293A
LowersteeringcolumntiltcontrolPressdownonthe
footpedal(1)atthebaseofthesteeringcolumntotiltthe
lowersteeringcolumntowardorawayfromyou
UppersteeringcolumntiltcontrolPushtheadjustment
lockhandle(2)towardthesteeringcolumnandtiltthe
uppersteeringcolumntowardorawayfromyou.
RAIL17SP00226AA4
Steeringwheeltelescopingadjustment-Thesteering
wheelcanbetelescopedinoroutbyturningthecenter
cap(1)counterclockwise,repositionthesteeringwheel
asneededandthenturningthecentercapclockwiseto
tighten.
RAIL17SP00299AA5
4-3
