6-WORKINGOPERATIONS
Boomoperation
Rightsideprimaryboomfoldin/out—Monoboom
DANGER
Electrocutionhazard!
Contactwithoverheadpowerlinescancausesevereelectricalburnsordeathfromelectrocution.
Makesurethereisenoughclearancebetweenequipmentandoverheadpowerlines.
Failuretocomplywillresultindeathorseriousinjury.
D0024A
NOTICE:Beforeunfoldingtherightsideboom,besuretoraisetheboomoutofthestoredpositiononthetransport
saddles.
ToUnfoldtherightsideprimaryboom(swingawayfrom
thevehicle):
1.Raisethecentersectiontofullheightbypressingthe
topofthecentersectionbutton(1).
NOTICE:Besuretoremovethecentersectiontransport
locksfromtheliftcylinders.
2.Raisetherightwingtilttofullliftheightbypressingthe
topoftherightsideboomtiltbutton(2).
3.Pushandholdthetopoftheswitch(3)tounfoldthe
primaryboom(moveawayfromthevehicle).
NOTE:Therightsideboomfoldswitchisspringloadedto
returntothecenter(Off)positionwhenreleased.
Tofoldtherightsideprimaryboom(swingtowardthe
vehicle):
1.Raisethecentersectiontofullheightbypressingthe
topofthecentersectionbutton(1).
2.Raisetherightwingtilttofullliftheightbypressingthe
topoftherightsideboomtiltbutton(2).
3.Pushandholdthebottomoftheswitch(3)tofoldthe
primaryboom(movebacktothevehicle).Becareful
thattheboomdoesnotgooverthetopoftheboom
restbackstop.
4.Pressthebottomoftherightsideboomtiltswitch(2)
tolowertheboomontotheboomrest.
RAIL17SP00391AA1
RAIL17SP00287AA2
NOTE:Tochangeyourjoystickgripbuttonpreferences,
usethearmrestdisplay.Select"OpPreference"then
"Grip."
