5-TRANSPORTOPERATIONS
Usethejoystickcontroltolowerboomagainstthetrans-
portstops.
1.Completelyraisetheleft-handandright-handbooms
usingtheleft-handtiltraisebutton(1)andtheright-
handtiltraisebutton(2)onthejoystick.
2.Lowertheboomcentersectiondownagainstthetrans-
portstopsontheliftcylindersusingthecentersection
raise/lowerbutton(3)onthejoystick.
3.Lowertheleft-handandtheright-handboomsback
intothetransportsaddlesusingtheleftandrightraise/
lowerbuttons(1)(2).Loweruntilalltensionisoffthe
tiltcylinders.
RAIL17SP00391AA5
Transportpreparationnalprocedure
1.Rotatetheamberrotatingbeaconsintothestorage
position.
Loosentheretainerthumbscrewlocatedonthewarn-
inglightpostandrotatetheentirepostwithbeacon
rearward.Tightenthethumbscrewtoholdthelightin
itsstoredposition.
2.Drivethevehicleontoaproperlysizedtrailer.
3.Placethejoystickcontrolintheneutral(N)position
lowerthesuspensionallthewaydownandapplythe
vehicleparkingbrake.Turnoffthevehicleengine.
4.Securethevehicletoatrailer.Tiedownthevehicleto
thetrailerusingthefourcornertiedownmethod.
Refertolocallawfortiedownmethodsinyourarea.
Securetiedownstothevehicle,butnevertovulnera-
bleareassuchascylinderrodsorsheetmetalareas.
5.Covertheexhaustopeningbytapingovertheopening
withducttapeoruseaexhaustpipecoverifavailable.
Thiswillkeeptheturbochargerfromspinningwithout
lubrication.
Besuretoremovethetapeorthecoverfromtheex-
haustbeforestartingtheengine.
Recoverytransport
Towingtheunit
Ifthevehiclemustbetowedandthevehiclehaslosten-
gineand/orhydraulicsystempower,theparkingbrakes
willautomaticallyapply.Theparkingbrakeisspringap-
pliedwhenhydraulicpressureislost.Contactyourdealer
forproperproceduretodisabletheparkingbrake.T ow
thevehicleatveryslowspeedsandonlyforaveryshort
distance.
NOTICE:Contactyourdealerforpropertowingproce-
dure.Failuretodosocancauseseveredamagetothe
drivesystem.
