6-WORKINGOPERATIONS
Rightsideprimaryboomswingin/out—SprayAirboom
DANGER
Electrocutionhazard!
Contactwithoverheadpowerlinescancausesevereelectricalburnsordeathfromelectrocution.
Makesurethereisenoughclearancebetweenequipmentandoverheadpowerlines.
Failuretocomplywillresultindeathorseriousinjury.
D0024A
NOTICE:Beforeunfoldingtherightsideboom,besuretoraisetheboomoutofthestoredpositiononthetransport
saddles.
Usethetiltcontrolbuttonsonthejoysticktotiltthebooms
allthewayupbeforestartingtounfoldorfoldthebooms.
Whenfoldingthebooms,besuretofoldthesecondary
boomsbeforefoldingtheprimarybooms.Usethetiltbut-
tonsonthejoysticktoleveltheboomsaftertheyarefolded
andtopositiontheboomscorrectlyintheboomrestsad-
dles.
ToUnfoldtherightsideprimaryboom(swingawayfrom
thevehicle):
1.Raisethecentersectiontofullheightbypressingthe
topofthecentersectionbutton(1)onthejoystick.
NOTICE:Besuretoremovethecentersectiontransport
locksfromtheliftcylinders.
2.Raisetherightwingtilttofullliftheightbypressingthe
topoftherightsideboomtiltbutton(2)onthejoystick.
3.Pushandholdthetopoftheswitch(3),onthemain
consolecontrolpanel,tounfoldtheprimaryboom
(moveawayfromthevehicle).
NOTE:Therightsideboomfoldswitchisspringloadedto
returntothecenter(Off)positionwhenreleased.
Tofoldtherightsideprimaryboom(movebacktothe
vehicle):
1.Raisethecentersectiontofullheightbypressingthe
topofthecentersectionbutton(1).
2.Raisetherightwingtilttofullliftheightbypressingthe
topoftherightsideboomtiltbutton(2).
RAIL17SP00391AA1
RAIL17SP00287AA2
6-13
