Miller Nitro 7380 - Hydraulic Reservoir Breather

To Next Page

To Previous Page

7-MAINTENANCE

Hydraulicreservoirbreather

1.Accessthehydraulicoilreservoir(1).Unlatchthefront

oftheenginecompartmentroofandpivotopen.

2.Removethecoverfromthebreatherhousingbyun-

screwingthecover.

3.Removethepaperelementinsidethebreatherhousing

andreplacewithanewpaperelement.

4.Replacethebreatherhousingcoverandtighten.

RAIL17SP00755AA1

RAIL17SP00769AA2

7-85
