7-MAINTENANCE

Hydraulicoillevel

1.Withtheengineshutoffandthekeyremoved,check

thehydraulicoillevelonthesightgauge(1).

RAIL17SP00755AA1

2.Iftheoilisnottothefullmark,addNEWHOLLAND

AMBRAHYDROSYSTEM68throughthellcap(2).

Hydraulicoiltankcapacityis132L(35USgal).

Usealtercarttolterallhydraulicoilbeforeitenters

thereservoir.

RAIL17SP00755AA2

7-44
