Miller Nitro 7380 - Right Side Secondary Boom Tip Fold In;Out - Mono Boom

6-WORKINGOPERATIONS
Rightsidesecondaryboomtipfoldin/out—Monoboom
DANGER
Electrocutionhazard!
Contactwithoverheadpowerlinescancausesevereelectricalburnsordeathfromelectrocution.
Makesurethereisenoughclearancebetweenequipmentandoverheadpowerlines.
Failuretocomplywillresultindeathorseriousinjury.
D0024A
NOTICE:Beforeunfoldingtherightsideboomtip,besuretounfoldtherightsideprimaryboom.
Whenfoldingorunfoldingthesecondarywing:
•
Unfolding:Havetheprimaryboomtiltedslightlydownwiththerightsideboomtiltbuttontoaidintheovercenter
traveloftheboomtip.
•
Folding:Havetheprimarywingtiltedupslightlywiththerightsideboomtiltbuttontoaidinbringingtheboomback
overcenter.
NOTE:Therightsideboomtiltswitch(1)isspringloaded
andwillreturntothecenter(Off)positionwhenreleased.
ToUnfoldtherightsidesecondaryboomtip:
1.Placethedriveinneutral.Systemwillnotoperate
unlessthejoystickisinneutral.
2.Pushandholdthetopoftheswitch(2)tounfoldthe
boomtip(moveawayfromtheprimaryboom).Switch
willilluminateredwhennotactive.Justastheboom
tipreachesthe90°position,pushandholdthebottom
oftheswitchtonishunfoldingtheboomtip.
Tofoldtherightsidesecondaryboomtip:
1.Placethedriveinneutral.Systemwillnotoperate
unlessthejoystickisinneutral.
2.Pushandholdthetopoftheswitch(2)tofoldthe
boomtip(movebacktotheprimaryboom).Switch
willilluminateredwhennotactive.Justastheboom
tipreachesthe90°position,pushandholdthebottom
oftheswitchtonishfoldingtheboomtip.
RAIL17SP00391AA1
RAIL17SP00287AA2
6-6
