7-MAINTENANCE
Fuselocations
Cabfuse/relayblock
TheCabfuse/relayblock(1)islocatedunderthestorage
binbehindthetrainingseat.
Removethebintoaccessthefuseblock.Removethe
fuseblockcovertoaccessthefuses.
Reinstallthefuseblockcoverandthestoragebinbefore
operatingthevehicle.
RAIL18SP01077AA1
ThefusesandrelayslocatedontheCabfuse/relayblockarelistedinthetable.
Fusenumber
RelaynumberAmperage
Description
F1K120A
StadiumLights1and6
F2K220A
StadiumLights2and5
F3K320A
StadiumLights3and4
F4K410ABeacons
F5K520A
BoomLights
F6K630A
WiperLow
F7K720ALowBeams
F8K820A
HighBeams
F9K930A
WiperHigh
—
K10
-
AutoSteer
—
K11
-
AutoSteer
—
K12
-
PressureFanRelay
—
K13
-
DoorSwitchRelay
—
K14
-
WiperFluidRelay
—
K15
-
EgressLightingRelay
F10
—
10A
SwitchedDisplayPower
F11
—
10A
SwitchedRadioPower
F12
—
15A
SwitchedDrivelineControlPower
F13
—
10A
110VOutletPower
F14
—
20A
AutoSteerValvePower
F15
—
30A
SwitchedOutletPower
F16
—
30A
EvaporatorBlowerPower
F17
—
20A
SeatPower
F18
—
15A
SwitchedFieldComputerPower
F19
—
10A
HVACPressureBlower
F20
—
10A
HVACPressureSensor
F21
—
10A
SwitchedHVACControlPower
F22
—
10A
ConstantHVACControlPower
F23
—
10A
CoolerPower
F24
—
10A
WiperFluidPumpPower
F25
—
30A
ConstantOutletPower
F26
—
10A
ConstantDisplayPower
F27
—
10APoweredMirrors
F28
—
10A
SteeringColumn
F29
—
10A
Spare
7-31
