Miller Nitro 7380 - Page 290

7-MAINTENANCE
Enginefuse/relayblock
TheEnginefuse/relayblock(1)islocatedonthecross
framebelowtheenginecompartment.
Openthelowerengineaccessdoors.
Reinstallthefuseblockcoverandclosethelowerengine
accessdoorsbeforeoperatingthevehicle.
RAIL17SP00758AA2
ThefusesandrelayslocatedontheEnginefuse/relayblockarelistedinthetable.
Fusenumber
RelaynumberAmperage
Description
F1K120A
BoomRestLights
F2K210A
RightAmber
F3K320A
PowerBeyond
F4K410A
SuspensionDump
F5K520A
ReverseLight/BackUpAlarm
F6K610A
EngineControlModule(ECM)SwitchedPower
F7K710AEductorWash
F8K810A
LeftAmber
F9K915A
Air-conditioningclutch
—
K10
-
Spare
—
K11
-
Spare
—
K12
-
Spare
—
K13
-
Spare
—
K14
-
EngineAuxiliaryRelay
—
K15
-
Spare
F10
—
20A
Spare
F11
—
10AFoamerPower
F12
—
15A
SensorPower
F13
—
25AProductValves
F14
—
15ANodePower
F15
—
15ABoomValves
F16
—
20A
ControlNodesHighCurrentpower
F17
—
15A
Spare
F18
—
10AAlternatorExciter
F19
—
30A
InjectionHighCurrentPower#2
F20
—
30A
InjectionHighCurrentPower#3
F21
—
30A
InjectionHighCurrentPower#1
F22
—
30A
EngineControlmodule(ECM)Constantpower
F23
—
20A
ISOBUSConstantpower
F24
—
10A
EgressLights
F25
—
25A
IntelliSpray™HighCurrentPower#1
F26
—
25A
IntelliSpray™HighCurrentPower#2
F27
—
25A
IntelliSpray™HighCurrentPower#3
F28
—
20A
EngineAuxiliaryRelayPower
F29
—
25A
IntelliSpray™HighCurrentPower#4
7-32
