Miller Nitro 7380 - Mono Boom - Grease - Mono Boom

7-MAINTENANCE
Monoboom-Grease—Monoboom
NOTE:Tolubricatetheboomttingsitmaybenecessarytolowerand/orunfoldtheboom.UseNEWHOLLAND
AMBRAGR-9MULTI-PURPOSEGREASEonallttings.
Primaryboompivots(eachendofcentersection)
Locatethevegreasettingsequallyspacedalongthe
tube(for100ftboomsandshorter)oneachprimary
pivotoneachsideofthecenterboomsection.Theunits
equippedwith120ftboomshavetwogreasettingsper
side(oneinthetopbushingandoneinthelowerbush-
ing).Cleanoffthegreasettingsbeforeattachingthe
greasegun.Greaseuntilgreasecomesoutofthetop
andbottomofthepivot.Wipeupanyexcessgrease.
Outeredge(1)ofcentersectionshown
RCPH11SPR081BAM1
Primaryboomtiltpivots
Locatetheinner(1)andouter(2)primaryboomtiltpin
greasettingsoneachprimaryboom.Cleanoffthe
greasettingsbeforeattachingthegreasegun.Grease
untilgreasecomesoutofthepivot.Wipeupanyexcess
grease.
RCPH11SPR082AAM2
RCPH11SPR083AAM3
