6-WORKINGOPERATIONS
Producttanksumpvalveswitch
Producttanksumpvalveon/offswitch
Thismomentaryswitch(1)allowstheoperatortoopen
andclosetheproducttanksumpfromtheoperatorcab.
Pressthebuttononcetoopenthesump.Pressthebutton
againtoclosethesump.Besuretoopenthesumpvalve
beforestartinganysprayingoperation.Theproducttank
sumpMUSTbeopenbeforestartingtheproductpump.
Theproducttanksumpcanalsobeopenedandclosed
fromoutsidetheoperatorcabusingtheremotesumpcon-
trolswitch.Theproducttanksumpicon(2)onthefront
overheaddisplaywillilluminatewhenthesumpisopen.
SumpMUSTbeopenwhenusingtheremotefastllfea-
ture.
NOTE:SumpMUSTbeopenwhenusingtheremotefast
llfeature.
NOTE:Whenyoushuttheengineoffwiththesumpopen,
thesumpwillremainopen.However,whenyourestartthe
engine,thesumpwillclose.Youwillneedtore-openthe
sumpbeforestartingtheproductpump.
RAIL17SP00287AA1
RAIL17SP00309FA2
Remoteproducttanksumpvalveopen/close
switch
Theremoteproducttanksumpswitch(1)allowstheop-
eratortoopenandclosethesumpfromoutsidethecab.
Theremotesumpswitchislocatedundertheframeon
thesideofthefastllsnorkel.Presstheswitchonthe
keypadoncetoopenthesump.Presstheswitchagain
toclosethesump.
The“SumpisOpen”light(2)inthefrontoverheaddisplay
willalsocomeonwhenopeningthesumpwiththisswitch.
Whenthisfeatureisactivewiththeremotekeypad,the
lightsatthetopoftheswitchwillilluminatesignifyingthat
thesumpisopen.Refertothefollowingtabletounder-
standwhateachlightorcombinationoflightsrepresent.
RAIL17SP00859AA3
RAIL17SP00309FA4
