Miller Nitro 7380 - Spray System Operation; Pressure Transducer Calibration

6-WORKINGOPERATIONS
Spraysystemoperation
RefertotheController'sInstallationandOperator’smanualsuppliedinthedocumentationpacketforcalibrationand
operatinginstructions.Calibratethesystemforthespeedandratedesired.
Thissprayerisequippedwithaowmeter(1)thatissized
tooptimizetheperformanceoftheproductapplication
system.Twoowmetersizesareavailabledependingon
themachineoptionthatwasinstalledonyourmachine.
Pleaselookattheowmeterlocatedontherightsideof
themachineneartheenginetoseehowyourmachineis
congured.
NOTE:Thisvalveisnevertruly“closed”.Productwillow
throughinbothpositions.
RAIL12SP00761AA1
Pressuretransducercalibration
Itisimportanttocalibratethepressuretransducersinitiallyandatthebeginningofeachsprayseason.
1.Ensurethattheproductsystemplumbingiscompletelydrained.
2.
Turntheignitionkeytotherunpositionandwaitforthecontrollerdisplaytostartup.
3.
OpentheVTMenuandselectthePCIIMenubutton.
4.
SelecttheToolsmenusoftkeyalongtherightsideofthedisplay.
5.
SelecttheSystemsSettingstabalongthetopofthedisplay.
6.
SelectthePressuresSettingsbutton.
7.
Withnoliquidintheproductsystemandtheproductpumpturnedoff,enter“0”fortheBoomPressureCaland
SpargePressureCal.
8.
SelecttheOKbutton.
9.
SelecttheHometoreturntotheVTrunscreen.
6-25
