6-WORKINGOPERATIONS
NOTE:IfyourmachineisequippedwithIntelliSpray™,leavethethrottlingvalveopenatalltimes.
Operation:
1.TurnOnratecontrollerandproductpump(seethe
controllermanual).
2.TurnOndesiredboomsections.
3.Beginforwardmotionandpushthetopofthespray
on/offswitch(1)toturnliquidowOn.
4.Increaseforwardspeeduntildesiredoperatingspeed
isreached.
5.Observecontrolconsoletodetermineifproperappli-
cationrateistakingplace.Ifnot,stopoperationand
refertocontrollermanuals.
6.ToturnOffliquidow,pushthemasterbutton(1).
RAIL17SP00391AA2
NOTICE:Operationwithboompressuresabove827kPa(120psi)isnotrecommended.Usecautionwhenincreas-
ingratesinthemanualmodetoavoidhighpressure.
Boomshut-off
Theboomplumbingpackageisequippedwithanelec-
tricshut-offvalveforeachboomsection.Theseelec-
tricshut-offvalvesarecontrolledbytheboomshut-off
switches(1)onthejoystickcontrol.Eachofthesesec-
tionsareconnectedtothespraycontrollersoproperacres
arecountedasvariousboomsectionsareshut-off.Each
sectionmusthavecorrectswathwidthprogrammedinto
themonitor.
RAIL17SP00391AA3
IntelliSpray™factorydefaultsettings
ValvetypePWM
PWM
frequency
50
MinPWM
10%
MinPWM
nozzle
25%
MaxPWM
85%
Responserate
35(default)
Deadband
1(default)
Pressure
reponse
default
Minpressure15PSI
Maxpressure135psi
6-26
