6-WORKINGOPERATIONS
Leftsideprimaryboomswingin/out—SprayAirboom
DANGER
Electrocutionhazard!
Contactwithoverheadpowerlinescancausesevereelectricalburnsordeathfromelectrocution.
Makesurethereisenoughclearancebetweenequipmentandoverheadpowerlines.
Failuretocomplywillresultindeathorseriousinjury.
D0024A
NOTICE:Beforeunfoldingtheleftsideboom,besuretoraisetheboomoutofthestoredpositiononthetransport
saddles.
ToUnfoldtheleftsideprimaryboom(swingawayfrom
thevehicle):
1.Raisethecentersectiontofullheightbypressingthe
topofthecentersectionbutton(1)onthejoystick.
NOTICE:Besuretoremovethecentersectiontransport
locksfromtheliftcylinders.
2.Raisetheleftwingtilttofullliftheightbypressingthe
topoftheleftsideboomtiltbutton(2)onthejoystick.
3.Pushandholdthetopoftheleftsideprimaryboom
switch(3)onthemainconsolecontrolpanel(move
awayfromthevehicle).
NOTE:Theleftsideprimaryboomswitchisspringloaded
toreturntothecenter(Off)positionwhenreleased.
Tofoldtheleftsideprimaryboom(swingtowardthe
vehicle):
1.Raisethecentersectiontofullheightbypressingthe
topofthecentersectionbutton(1).
2.Raisetheleftwingtilttofullliftheightbypressingthe
topoftheleftsideboomtiltbutton(2).
3.Pushandholdthebottomoftheleftsideprimaryboom
switch(3)(movebacktothevehicle).
4.Pressthebottomoftheleftsideboomtiltswitch(2)to
lowertheboomontotheboomrest.
RAIL17SP00391AA1
RAIL17SP00287AA2
