6-WORKINGOPERATIONS
Rightsidesecondaryboomtipfoldin/out—Trussboom—Truss
boom
DANGER
Electrocutionhazard!
Contactwithoverheadpowerlinescancausesevereelectricalburnsordeathfromelectrocution.
Makesurethereisenoughclearancebetweenequipmentandoverheadpowerlines.
Failuretocomplywillresultindeathorseriousinjury.
D0024A
NOTE:Unfoldtherightsideprimaryboombeforeunfoldingtherightsidesecondaryboom.Referto6-5
NOTE:Therightsidesecondaryboomfoldswitch(1)is
springloadedtoreturntothecenter(Off)positionwhen
released.
ToUnfoldtherightsidesecondaryboomtip:
1.Placethedriveinneutral.Systemwillnotoperate
unlessthejoystickisinneutral.
2.Pushandholdthetopoftherightsidesecondaryboom
switch(1)onthemainconsolecontrolpanel(move
awayfromtheprimaryboom).Switchwillilluminate
redwhennotactive.Holdtheswitchpositionuntilthe
secondaryboomiscompletelyunfolded.
Tofoldtherightsidesecondaryboom:
1.Placethedriveinneutral.Systemwillnotoperate
unlessthejoystickisinneutral.
2.Pushandholdthebottomoftherightsidesecondary
boomswitch(1)(movebacktotheprimaryboom).
Switchwillilluminateredwhennotactive.Holdthe
switchpositionuntilthesecondaryboomiscompletely
folded.
RAIL17SP00287AA1
6-10
