Miller Nitro 7380 - Control Identification - Luxury Cab

3-CONTROLSANDINSTRUMENTS
Controlidentication—Luxurycab
WARNING
Lossofcontrolhazard!
DONOTmakeseatadjustmentswhilethemachineisinmotion.Allseatadjustmentshouldbemade
withthemachinestationaryandtheparkingbrakeapplied.
Failuretocomplycouldresultindeathorseriousinjury.
W0293A
Thefollowingisalistofadjustmentsfortheseatandseat
suspension:
Fore/aftisolator(1)—Undercertaindrivingconditions
youmaywanttheoperator’sseattoabsorbsudden
shocksasinsuddenstops.Theisolatorhastwoposi-
tions.Isolatoroff(position1)pointingforwardorisolator
on(position2)pointingrearward.
Aftertheadjustmentofposition1,thelockinglevermust
latchintothedesiredposition.Forthat,theseatmustbe
pressedbackwardsuntilitlatcheswithanaudibleclick.
Itshouldnotbepossibletomovethefore/aftisolatorinto
anotherpositionwhenitislocked.
Damperadjustment(2)—Thedampersettingoftheseat
canbevariedtosuitdifferentdrivingconditions.Turnthe
levertothedesiredposition.1:Hardestto5:Softest.
Heightandweightadjustment(3)—Thiscontrolwillraise
andlowerthesuspension.Thekeymustbeoninorder
forthisadjustmenttofunction.Theseatisraisedusinga
smallonboardcompressor.
Neveroperatethecompressorformorethanoneminute.
Pressthetopoftherockerswitchandtheseatwillrise
andthesuspensionwillbecomermer.Pressthebottom
oftherockerswitchandtheseatwilllowerandthesus-
pensionwillbecomesofter.Releasetheswitchanditwill
returntothecenter(off)position.
Seatfore/aftadjustment(4)—Liftthecontrolupandslide
theseatfore/aft.Releasethecontrolandlockintoposi-
tion.Besurethecontrollocks.Donotuseyourlegtopull
thiscontrol.
RAIL17SP00297AA1
Seatdepthadjustment(5)—Pulluponthecontrolto
movetheseatcushionbackandforth.Thiscontrolonly
movestheseatcushion,nottheentireseat.Besurethe
adjustmentlocksintoposition.
Seatpanangleadjustment(6)—Pulluponthecontrol,
thentilttheseatforwardorbackwarduntilyoureachthe
desiredangle.Releasethecontroltolocktheseatinthat
position.
RAIL17SP00295AA2
3-3
