3-CONTROLSANDINSTRUMENTS
Lateral/horizontalsuspensionlock(7)—Thiscontrolis
locatedontheleft-handsideoftheseat.Pushbackon
thelevertounlockthiscontrol.Whencontrolisunlocked
theseatisallowedtomoveslightlysidetosidetoabsorb
anyslightchangesinterrain.Pushtheleverforwardto
locktheseatandkeepitfrommovingsidetoside.
RAIL17SP00266AA3
Backrestadjustment(8)—Locatedontheleft-handrear
sideoftheseat,pulluponthelevertomovetheback-
resttoanotherposition.Onceacomfortablepositionis
reached,releasethelevertolockintoposition.Thislever
alsoallowsyoutofoldtheseatbackrestallthewaydown
toaccessthestoragenetbehindtheseat.Besurethe
adjustmentislockedinposition.
Lumbarsupportadjustment(9)—Withtheupperand
lowerswitchthecurvatureintheupperandlowerarea
ofthebackrestupholsterycanbeindividuallyadjusted.
Thisincreasesboththeseatingcomfortandtheperfor-
manceofthedriver.Thelumbarcurvaturecanbein-
creasedpressingthe“+”orreducedbypressingthe“-”on
therelevantswitch.Whenthebackrestupholsterydoes
nolongerreactbypressingthe“+”,themaximumcurva-
turehasbeenreachedandtheswitchshouldbereleased.
RAIL17SP00223AA4
Seatheaterandseatventilation(10)—Theseatventi-
lationsystemmakessurethattheseatsurfaceremains
dry.Humidityinthecontactareaoftheseatwillbetaken
away.Thisensuresacomfortable,coolandcleanseat
feeling.Operatethisswitchtoactivateordeactivatethe
seatheaterandtheseatventilation.Therockerswitchis
athreepositionswitch:withtheswitchinthecenterposi-
tiontheseatheaterandseatventilationisOFF .Pushthe
topoftheswitchintoturntheseatheaterON(seatven-
tilationOFF).Pushthebottomoftheswitchintoturnthe
seatventilationON(seatheaterOFF).
RAIL17SP00296AA5
Controlconsoleonlyfore/aftadjustment(11)—Thiscon-
trolisusedtoadjusttheconsoleonlyinrelationtotheseat
position.Besuretheconsoleislockedinpositionbefore
operating.
