Miller Nitro 7380 - Left Side Secondary Boom Tip Fold In;Out - Spray Air Boom

6-WORKINGOPERATIONS
Leftsidesecondaryboomtipfoldin/out—SprayAirboom
DANGER
Electrocutionhazard!
Contactwithoverheadpowerlinescancausesevereelectricalburnsordeathfromelectrocution.
Makesurethereisenoughclearancebetweenequipmentandoverheadpowerlines.
Failuretocomplywillresultindeathorseriousinjury.
D0024A
NOTE:Unfoldtheleftsideprimaryboombeforeunfoldingtheleftsidesecondaryboom.Referto6-15
NOTE:Theleftsidesecondaryboomfoldswitch(1)is
springloadedtoreturntothecenter(Off)positionwhen
released.
ToUnfoldtheleftsidesecondaryboomtip:
1.Placethedriveinneutral.Systemwillnotoperate
unlessthejoystickisinneutral.
2.Pushandholdthetopoftheleftsidesecondaryboom
switch(1)onthemainconsolecontrolpanel(move
awayfromtheprimaryboom).Switchwillilluminate
redwhennotactive.Holdtheswitchpositionuntilthe
secondaryboomiscompletelyunfolded.
Tofoldtheleftsidesecondaryboom:
1.Placethedriveinneutral.Systemwillnotoperate
unlessthejoystickisinneutral.
2.Pushandholdthebottomoftheleftsidesecondary
boomswitch(1)(movebacktotheprimaryboom).
Switchwillilluminateredwhennotactive.Holdthe
switchpositionuntilthesecondaryboomiscompletely
folded.
RAIL17SP00287AA1
6-16
