7-MAINTENANCE

Kingpins-Grease

NOTE:UseNEWHOLLANDAMBRAGR-9MULTI-PURPOSEGREASEonallttings.

Frontsteeringpivotkingpins

Locatethegreasettingsoneachofthefrontsteering

pivotkingpins.Tworemotettingsonthetop(1)(re-

motemountedtowardfrontofunit)andonettingon

thebottom(2)ofeachpivot.Cleanoffgreasettings

beforeattachingthegreasegun.Greasebothttings

untilgreasecomesoutofthekingpintube.Wipeup

excessgrease.

RAIL12SP01190AA1

RCPH11SPR092AAM2

7-57
