7-MAINTENANCE
Flowmetercable
Disconnectthecablefromtheowmeter.Holdow
metercablesothatthe“lockingtab”(4)isatthetop.
(1)=Signal
(2)=Ground
(3)=Power
RAIL17SP01389AA1
Procedure
1.FindtheMETERCALontheconsoleandrecordthat
number.EnteraMETERCALnumberofone(1)inthe
console.
2.Depressthekeyontheconsolelabeled“TotalVolume”
onlowerrowofkeypad.
3.PlaceboomswitchespowerandmasterswitchtoON.
4.Withasmalljumperwire,createashortbetweenthe(1)
and(2)socketswitha“short-noshort”motion.Each
timeacontactismade,theTOTALVOLUMEshould
incrementup1ormorecounts.
5.IfTOTALVOLUMEdoesnotcountup,removethesec-
tionofcableandrepeatthetestattheconnectornext
closesttotheconsole.Replacedefectivecableasre-
quired.
6.Performallvoltagechecks.
7.Ifallcablestestgood,replacetheowmeter.
NOTE:Aftertestingiscomplete,re-entercorrectMETER
CALnumbersbeforeapplication.Themetercalibration
numberwillbelocatedonthetagattachedtotheowme-
terwires.
7-101
