6-WORKINGOPERATIONS
Leftsideprimaryboomswingin/out—Monoboom
DANGER
Electrocutionhazard!
Contactwithoverheadpowerlinescancausesevereelectricalburnsordeathfromelectrocution.
Makesurethereisenoughclearancebetweenequipmentandoverheadpowerlines.
Failuretocomplywillresultindeathorseriousinjury.
D0024A
NOTICE:Beforeunfoldingtheleftsideboom,besuretoraisetheboomoutofthestoredpositiononthetransport
saddles.
ToUnfoldtheleftsideprimaryboom(swingawayfrom
thevehicle):
1.Raisethecentersectiontofullheightbypressingthe
topofthecentersectionbutton(1).
NOTICE:Besuretoremovethecentersectiontransport
locksfromtheliftcylinders.
2.Raisetheleftwingtilttofullliftheightbypressingthe
topoftheleftsideboomtiltbutton(2).
3.Pushandholdthetopoftheswitch(3)tounfoldthe
primaryboom(moveawayfromthevehicle).
NOTE:Theleftsideboomfoldswitchisspringloadedto
returntothecenter(Off)positionwhenreleased.
Tofoldtheleftsideprimaryboom(swingtowardthe
vehicle):
1.Raisethecentersectiontofullheightbypressingthe
topofthecentersectionbutton(1).
2.Pressthetopoftheleftsideboomtiltbutton(2)totilt
theboomtofullheight.
3.Pushandholdthebottomoftheswitch(3)tofoldthe
primaryboom(movebacktothevehicle).Becareful
thattheboomdoesnotgooverthetopoftheboom
restbackstop.
4.Pressthebottomoftheleftsideboomtiltswitch(2)to
lowertheboomontotheboomrest.
RAIL17SP00391AA1
RAIL17SP00287AA2
6-7
