6-WORKINGOPERATIONS

Handrinsewatervalves

Therearetwohandrinsewatervalves.Oneislocatedat

theleft-handsideoftherinsewatertank(1)andisahand

operatedon/offvalve(2).Thesecondislocatedonthe

fastllsnorkel(3)andisalsoahandoperatedon/offvalve

(4)

RAIL17SP00763AA11

RAIL17SP00859AA12

6-21
