4-OPERATINGINSTRUCTIONS
6.Checkthetoeatthefrontwheels(1).Besurethe
wheelsaresquarewitheachotherrst.Findthecen-
teroftherimatthefrontandrearofeachfronttire.
Marktherimsatbothofthesepoints.Useatapemea-
suretomeasurethedistancefromtheinsideofthe
frontoftheleftrimtotheinsideoftherearoftheright
rim.Repeatbymeasuringfromthefrontoftheright
rimtotherearoftheleftrim.Thesetwodimensions
shouldbethesame.Measurethedistanceacrossthe
frontoftherims.Attherearoftherimmeasurethe
distanceacrossrearoftherims.Thefrontdimension
shouldbe6.35–19.05mm(0.25–0.75in)lessthan
therearmeasurement.Ifthetoe-inisnotwithinthis
rangefronttoback,adjustbothcylinderrodsequally
untilpropertoeisachieved.Besuretoretightenthe
clevisjamnutsafteradjusting.
RAIL14SP01012AA2
7.Checkthetoeattherearwheels.Besurethewheels
aresquarewitheachotherrst.Findthecenterofthe
rimatthefrontandrearofeachreartire.Markthe
rimsatbothofthesepoints.Useatapemeasureto
measurethedistancefromtheinsideofthefrontof
theleftrimtotheinsideoftherearoftherightrim.
Repeatbymeasuringfromthefrontoftherightrimto
therearoftheleftrim.Thesetwodimensionsshould
bethesame.Measurethedistanceacrossthefrontof
therims.Attherearoftherimmeasurethedistance
acrossrearoftherims.Thefrontdimensionshould
be0.00–12.70mm(0.00–0.50in)lessthantherear
measurement.Ifthetoe-inisnotwithinthisrangefront
toback,adjustbothcylinderrodsequallyuntilproper
toe-inisachieved.Besuretoretightentheclevisjam
nutsafteradjusting.
RAIL14SP01013AA3
4-15
