6-WORKINGOPERATIONS

Producttankfastll

Frontofunitbelowcab.

RAIL12SP01059AA5

Rinsewatertankfastll

Frontofunitbelowcab.

RAIL12SP01059AA6

Quickattachvalves

Thereareseveralvalvesontheliftarms(dependingon

optionsinstalled).Besuretoclosethesevalvesbefore

disconnectingthemainproductcircuit(2)disconnector

therearnozzle(1)disconnect.Thesevalvesshouldre-

mainclosedwhentheboomisremoved.

Ifyourvehiclehasa10sectionboom,therewillbean

additionalrearnozzleshutoffanddisconnectontheright

sideliftarm.

RAIL12SP01217AA7

6-19
