7-MAINTENANCE

Boomguidewheelpivot

Locatethegreasetting(1)ontheguidewheelpivot

tube(2).Cleanoffthegreasettingbeforeattaching

thegreasegun.Greaseuntilgreasecomesoutofthe

pivot.Wipeupexcessgrease.Repeatfortheguide

wheelpivotontheotherboom.

RAIL15SP00906AA6

Secondaryboomcylinderrodandbaseendpivots

Locatethegreasettings(1)onthecylinderrodend(2)

andthecylinderbaseend(3)betweentheprimaryand

secondarybooms.Cleanoffthegreasettingsbefore

attachingthegreasegun.Greaseuntilgreasecomes

outofthepivots.Wipeupexcessgrease.Repeatfor

thesecondaryboomcylinderpivotsontheotherboom.

RAIL15SP00907AA7

RAIL15SP00908AA8

7-52
