3-CONTROLSANDINSTRUMENTS
ReferencenumberSwitchdescription
5
Right-handsidesecondaryboomfold/unfold
6Enginespeedcontrol
7
Parkbrakeswitch
8
Spargeincrease
9
Spargedecrease
10
Productpumpon/off
11
Productsumpon/off
12Boomblowout
13
Right-handsidefencerow
14
Left-handsidefencerow
15
Producttankrinsenozzleson/off
16Rinsesump
Left-handsideprimaryboomswingin/out
Thisswitch(1)isusedtoswingtheprimaryboomout
awayfromthevehicleandbacktowardthevehicle.Refer
to6-11forcompleteoperationdetails.
RAIL17SP00287AA2
Left-handsidesecondaryboomfold/unfold
Thisswitch(1)isusedtofoldorunfoldthesecondary
boomfromtheprimaryboom.Referto6-12forcomplete
operationdetails.
RAIL17SP00287AA3
Right-handsideprimaryboomswingin/out
Thisswitch(1)isusedtoswingtheprimaryboomout
awayfromthevehicleandbacktowardthevehicle.Refer
to6-9forcompleteoperationdetails.
RAIL17SP00287AA4
