3-CONTROLSANDINSTRUMENTS
Remoterinsetanksumpvalveopen/close
switch
Theremoterinsetanksumpswitch(1)allowstheoperator
toopenandclosethesumpfromoutsidethecab.Press
theswitchtoopenthesump.Whenthesumpisopen,
thefourledlightsontheswitchwillilluminateindicating
thatthesumpisopen.Presstheswitchagaintoclose
thesump.
Whentherinsetanksumpvalveisopen,therinsetank
icon(2)onthefrontoverheadpanelwillilluminate.
RAIL17SP00859AA10
RAIL17SP00309FA11
Chemicaleductoron/offswitch
Thechemicaleductoron/offswitchisusedtoturnthe
chemicaleductoronandoff.Presstheswitchtoturnthe
chemicaleductoron.Whentheeductorisonthefourled
lightsontheswitchwillilluminateindicatingtheeductoris
on.Presstheswitchagaintoturnthechemicaleductor
off.Besurethechemicaleductorlidisclosedwhenusing
theeductor.
NOTE:Whenthechemicaleductorswitchisactivated,:
theenginewillrevupandthepumpwillstart.Thesehap-
penautomatically.
RAIL17SP00859AA12
Chemicaleductorrinseon/offswitch
Thechemicaleductorrinseon/offswitchisusedtorinse
theinsideoftheeductorhopper.Presstheswitchtoturn
thechemicaleductorrinseon.Whentheeductorrinseis
onthefourledlightsontheswitchwillilluminateindicating
thattherinseison.Presstheswitchagaintoturnthe
chemicaleductorrinseoff.Besurethechemicaleductor
lidisclosedwhenusingtheeductorrinse.
RAIL17SP00859AA13
