System Tab System Interface
3 - 48 046-004667-00 A7™ Operating Instructions
Configure Serial Select:
• Protocol (None (default), HL7, MR-WATO, Philips
(software bundle version 02.09.00 and later))
• Baud Rate (57600, 11520 (default))
• Data Bits (8 (default), 7, 6, 5)
• Stop Bits (1 (default), 2)
• Parity (Odd, Even, None (default))
• Interval:
Enabled when Protocol=None: Off (default);
Enabled when Protocol=HL7:10 Sec, 30 Sec, 1
Min (default), 5 Min, 30 Min, 1 Hour, 2 Hour, 6
Hour, 12 Hour, 24 Hour.
NOTE: When Protocol is set to MR-WATO,
the A7 can communicate with the
patient monitor of Mindray
through Benelink module of
Mindray.
NOTE: When Protocol is set to Philips, the
A7 can communicate with the
patient monitor of Philips through
IntelliBridge or VueLink module of
Philips.
Network Protocol
SETTINGS PARAMETERS
