System Softkeys System Interface
3 - 34 046-004667-00 A7™ Operating Instructions
3.9.5.2.4 Display Groups
Display Group allows for the trends to be displayed in a specified parameter group.
Set Display Group to Gas, Fresh Gas, Ventilation, or All.
3.9.5.2.5 Graphic Trends Export
The Export button on the Graphic Trends tab will allow the contents of the history to be exported
to a USB mass storage device. The format of the data exported is a .html file which can be opened
using Internet Explorer version 6.0, 7.0 and 8.0. The Export button on the Graphic Trends tab is only
available when the system is in Standby mode.
NOTE: If Internet Explorer greater than version 8.0 is used to view the
exported file, set it to compatibility mode.
3.9.5.3 Event Log
Select the History button on the main screen and then select the Event Log tab to access the Event
Log. The History dialog displays (see FIGURE 3-42) with the Event Log tab selected.
FIGURE 3-42 Event Log
The Event Log tab logs such events as technical alarms, physiological alarms, capture events, delay
power off, end case, delay power off canceled and system time change. Events can be physiological
indicating that a patients physiological alarm thresholds have been violated or technical indicating
that a specific technical issue has occurred.
An alarm entry and captured events in the Event Log displays the time, date, event, priority and
additional information which includes the ventilation mode, patient size, and monitored parameters.
NOTE: The Event log will be cleared after the anesthesia machine
undergoes a power failure or is turned off. To view event log,
contact Mindray Customer Service.
3.9.5.3.1 Navigating in Event Log
The dialog navigation buttons are described in TABLE 3-7.
