A7™ Operating Instructions 046-004667-00 9 - 11
Product Specifications Breathing System Specifications
9.8.6 Resistance
Resistance of APL valve in dry gas (Lift the APL Valv):
Resistance of APL valve in wet gas (Lift the APL Valv):
TABLE 9-17
APL Valve
Flow (L/min)
Pressure drop (kPa)
Flow(L/min)
Pressure drop (kPa)
Expiratory resistance in mechanical ventilation mode:
TABLE 9-18
Resistance
Pressure drop(kPa)
Flow (L/min)

Mindray A7 Specifications

General

Type	Anesthesia Workstation
Brand	Mindray
Model	A7
Display	15-inch color touchscreen
Oxygen Flush	Yes
Gas Inlets	O2, N2O, Air
Ventilation Modes	SIMV, PSV
Breathing System	Integrated
Gas Monitoring	O2, CO2, N2O
Monitoring Parameters	FiO2
CO2 Monitoring	Mainstream or Sidestream
Power Supply	100-240 V, 50/60 Hz
