Mindray A7 Operating Instructions

A7™ Operating Instructions 046-004667-00 7 - 19
Maintenance Cleaning and Disinfection
7.9.9 Absorber Canister
1. Locate the condensate drain valve at the bottom of the absorber canister assembly.
FIGURE 7-16 Condensate Drain Valve Location
FIGURE 7-17 Condensate Drain Valve (Close Up View)
2. While holding a small cup below the drain, turn the condensate drain valve clockwise to
open the drain and collect any water that may have gathered. Turn the drain valve counter-
clockwise to close the drain. Discard any water collected.
WARNING: Use extreme care while handling the absorbent as it contains a caustic
irritant.
3. Rotate the locking mechanism handle clockwise into the unlocked position (see FIGURE 7-
18). This separates the absorber canister from the top of the assembly. While noting the
previous WARNING, remove the absorber canister. Then remove the Pre-Pak or loose fill
absorbent from the canisters. Dispose of the absorbent as per the local regulations.
Absorber Canister
Condensate Drain
Turn the condensate
drain valve to open
and close

Mindray A7 Specifications

General

Type	Anesthesia Workstation
Brand	Mindray
Model	A7
Display	15-inch color touchscreen
Oxygen Flush	Yes
Gas Inlets	O2, N2O, Air
Ventilation Modes	SIMV, PSV
Breathing System	Integrated
Gas Monitoring	O2, CO2, N2O
Monitoring Parameters	FiO2
CO2 Monitoring	Mainstream or Sidestream
Power Supply	100-240 V, 50/60 Hz
