A7™ Operating Instructions 046-004667-00 7 - 25
Maintenance Cleaning and Disinfection
7.9.11 Active AGSS (Anesthetic Gas Scavenging System) and AGSS
Transfer Hose
1. Disconnect the EVAC hose from the AGSS (see FIGURE 7-25).
2. Remove the AGSS and Transfer Hose from the A7.
FIGURE 7-25 AGSS and Transfer Hose Removal
3. Clean the outer surface of the AGSS and Transfer Hose with a soft, lint-free cloth and a
recommended cleaning agent (see TABLE 7-2 on page 7-8). Allow to dry thoroughly.
4. Remove the top of the AGSS (see FIGURE 7-26). Inspect the AGSS filter and shake it over a
waste container to clean it as necessary. If the filter must be replaced, dispose of the old filter
per local disposal regulations.
EVAC Hose Port
Transfer Hose
To Next Page
