Monitor Module Product Specifications
9 - 14 046-004667-00 A7™ Operating Instructions
9.11 Monitor Module
9.11.1 AG Module
Minimum Flow 20 L/min suction
Vacuum Gauge Accuracy +/- 5 % of full scale
TABLE 9-22
Suction device
Measurement mode: Sidestream
Warm-up time: ISO accuracy mode: < 45 s
Full accuracy mode: <10 min
Sampling rate: Sampling rate:
The type of AG Watertrap is high volume: 120/150/200 ml/
min
The type of AG Watertrap is low volume: 70/90/120 ml/min
Accuracy: ± 10 ml/min or ± 10 %, whichever is greater
Watertrap emptying interval (half full,
worst case):
The type of AG Watertrap is high volume: 17 h @ 200 ml/
min, 37 °C, 100 % RH
The type of AG Watertrap is low volume: 20 h @ 120ml/min,
37 °C, 100 % RH
Gas: CO
2
, O
2
(Paramagnetic O
2
module), N
2
O, and any of the five
anesthetic agents: DES, ISO, ENF, SEV and HAL.
Range: CO
2
: 0 to 30 %
O
2
: 0 to 100 %
N
2
O : 0 to 100 %
DES : 0 to 30 %
SEV : 0 to 30 %
ENF : 0 to 30 %
ISO : 0 to 30 %
HAL : 0 to 30 %
ISO accuracy mode As Full accuracy specifications, but derated as follows:
Add ± 0.3 %
ABS
to accuracy for CO
2
;
Add ± 8 %
REL
to accuracy for all agents;
N
2
O accuracy is ± (8 %
REL
+ 2 %
ABS
).
1):
10 % to 90 %. Sample gas flow: 200 ml/min. DRYLINE
TM
watertrap. Adult DRYLINE
TM
sampling line (2.5 m).
2):
10 % to 90 %. Sample gas flow: 120 ml/min. DRYLINE
TM
watertrap. Pediatric DRYLINE
TM
sampling line (2.5 m).
TABLE 9-23
AG Module
