A7™ Operating Instructions 046-004667-00 8 - 5
AG and O2 Concentration Monitoring Agent Consumption Speed (Software Bundle Version 02.11.00 or later)
8.4 Agent Consumption Speed (Software Bundle
Version 02.11.00 or later)
When anesthesia system is configured with internal AG module, A7 can calculate the agent
consumption speed (the approximately agent used per hour) and the cost.
FIGURE 8-2 Agent Consumption Speed
To set the cost per hour:
1. Select Setup softkey > System tab (system password needed) > Optimizer® button.
2. Set the cost of the anesthsia agent per hour to display cost.
8.5 Identify External AG Modules
FIGURE 8-3 External AG Module
NOTE: The AG module (see FIGURE 8-3) is configured with the function of
compensating barometric pressure automatically.
NOTE: The hardkey on the AG module has been disabled.
Displays the real-
time agent used
per hour.
Agent Comsumption Speed
Displays the
instantaneous
agent cost per
hour. The value is
determined by the
real-time agent
used per hour
multiplied by the
agent cost set in
system menu.
Gas outlet
Indicator
Watertrap socket

Mindray A7 Specifications

General

Type	Anesthesia Workstation
Brand	Mindray
Model	A7
Display	15-inch color touchscreen
Oxygen Flush	Yes
Gas Inlets	O2, N2O, Air
Ventilation Modes	SIMV, PSV
Breathing System	Integrated
Gas Monitoring	O2, CO2, N2O
Monitoring Parameters	FiO2
CO2 Monitoring	Mainstream or Sidestream
Power Supply	100-240 V, 50/60 Hz
