Mindray A7 Operating Instructions

Display Tab System Interface
3 - 38 046-004667-00 A7™ Operating Instructions
3.11 Display Tab
The Display tab provides access to screen cleaning, screen calibration, pressure parameter display,
CO2 waveform placement, gas scales, waveform display, screen brightness and key click volume (see
FIGURE 3-45).
Screen Brightness
To adjust the screen brightness:
1. Select Setup softkey > Display tab (See FIGURE 3-45).
2. In the Screen Brightness area, select the +/- buttons to adjust the screen brightness.
3. Select the Accept button to confirm the change, or select Cancel to discard the change.
FIGURE 3-45 Display Tab > Screen Brightness Area
Select the +/- buttons to
adjust screen brightness.

Mindray A7 Specifications

General

Type	Anesthesia Workstation
Brand	Mindray
Model	A7
Display	15-inch color touchscreen
Oxygen Flush	Yes
Gas Inlets	O2, N2O, Air
Ventilation Modes	SIMV, PSV
Breathing System	Integrated
Gas Monitoring	O2, CO2, N2O
Monitoring Parameters	FiO2
CO2 Monitoring	Mainstream or Sidestream
Power Supply	100-240 V, 50/60 Hz
