3.5 Spirometry Tab
Displays separate looped graphs and waveforms (See FIGURE 3-24).
You can press the button (see FIGURE 3-24) to only view the spirometry loop (see FIGURE 3-25).
FIGURE 3-24 Spirometry and Waveforms
Spirometry Tab
