Mindray A7 Operating Instructions

A7™ Operating Instructions 046-004667-00 9 - 15
Product Specifications Monitor Module
Full accuracy mode Gas Range (%
REL
)Accuracy (%
ABS
)
CO
2
0 to 1 ± 0.1
1 to 5 ± 0.2
5 to 7 ± 0.3
7 to 10 ± 0.5
> 10 Unspecified
N
2
O0 to 20± 2
20 to 100 ± 3
O
2
0 to 25 ± 1
25 to 80 ± 2
80 to 100 ± 3
DES 0 to 1 ± 0.15
1 to 5 ± 0.2
5 to 10 ± 0.4
10 to 15 ± 0.6
15 to 18 ± 1
> 18 Unspecified
SEV 0 to 1 ± 0.15
1 to 5 ± 0.2
5 to 8 ± 0.4
> 8 Unspecified
ENF, ISO, HAL 0 to 1 ± 0.15
1 to 5 ± 0.2
> 5 Unspecified
Rise time @ 200 ml/min
1)
CO
2
: ≤ 250 ms
O
2
: ≤ 500 ms
N
2
O : ≤ 250 ms
ENF : ≤ 350 ms
DES, SEV, ISO, HAL: ≤ 300 ms
Rise time @ 120 ml/min
2)
CO
2
: ≤ 250 ms
O
2
: ≤ 500 ms
N
2
O : ≤ 250 ms
ENF : ≤ 350 ms
DES, SEV, ISO, HAL: ≤ 300 ms
Delay time < 4 s
Update time Once per second
Calibration Once per year
Primary agent ID threshold 0.15 % (0.4 % during ISO accuracy mode)
Secondary agent ID threshold 0.3 % (0.5 % during ISO accuracy mode) or 5 %
REL
(10 %
REL
for Isoflurane) of primary agent if primary agent >10 %
Agent ID time Less than 3 breaths, typically 12 seconds
1):
10 % to 90 %. Sample gas flow: 200 ml/min. DRYLINE
TM
watertrap. Adult DRYLINE
TM
sampling line (2.5 m).
2):
10 % to 90 %. Sample gas flow: 120 ml/min. DRYLINE
TM
watertrap. Pediatric DRYLINE
TM
sampling line (2.5 m).
TABLE 9-23
AG Module

Mindray A7 Specifications
