A7™ Operating Instructions 046-004667-00 3 - 35
System Interface System Softkeys
NOTE: Disabled navigation buttons indicate that there is no more data
available or the end of the data range was reached.
3.9.5.3.2 Event Log Filter
The Filter button displays the Event Log Entries trends similarly to the Event type.
Set Filter to High, Medium, Low, Informational or All. The A7 displays the corresponding event
based on your setting.
3.9.5.3.3 Event Log Export
The Export button on the Event Log tab exports the contents of the event log to a USB mass storage
device. The format of the data exported is an .html file which can be opened using Internet Explorer
version 6.0, 7.0 and 8.0. The Export button on the Event Log tab is only available when the system is
in Standby mode.
NOTE: If Internet Explorer greater than version 8.0 is used to view the
exported file, set it to compatibility mode.
BUTTON FUNCTION
Moves the cursor up one record from its current position.
Moves the cursor down one record from its current position.
Moves the cursor up one page from its current position.
Moves the cursor down one page from its current position.
Moves the scroll to the top most record from its current position.
Moves the scroll to the bottom most record from its current
position.
TABLE 3-7
