Ventilation Parameter Relationships Parameters and Factory Defaults
C - 14 046-004667-00 A7™ Operating Instructions
NOTE: Even when the PlimVG, Pinsp, or ΔP parameters are inactive, they are restricted to the
parameter relationship equations.
PCV Rate
4 ≤ Rate ≤ 100
VtG If VtG is not Off.
20 ≤ Vt ≤ 1500
Pinsp Pinsp ≥ PEEP+5
5 ≤ Pinsp ≤ 70
PlimVG PlimVG ≥ PEEP+5
5 ≤ PlimVG ≤ 100
SIMV-PC Rate
4 ≤ Rate ≤ 100
Pinsp Pinsp ≥ PEEP+5
5 ≤ Pinsp ≤ 70
VENTILATION
MODE Parameter
Parameter
Relationship Equation (s)

Mindray A7 Specifications

General

Type	Anesthesia Workstation
Brand	Mindray
Model	A7
Display	15-inch color touchscreen
Oxygen Flush	Yes
Gas Inlets	O2, N2O, Air
Ventilation Modes	SIMV, PSV
Breathing System	Integrated
Gas Monitoring	O2, CO2, N2O
Monitoring Parameters	FiO2
CO2 Monitoring	Mainstream or Sidestream
Power Supply	100-240 V, 50/60 Hz
