Mindray A9 Service Manual

3-4
8. Remove the protection foam at the rear of the base, cut the flexible packing tape at the front
and rear of the main unit, and finally remove the display mounting plate protection foam
block, front packing belt protection wood, and rear packing belt protection foam.
9. Remove the protection foam and front baffle from the front of the base. Then remove the
protection foam from the left and right of the base.
Protection foam at the rear of the
base
Flexible packing
Rear packing belt protection foam
Front packing belt protection
wood
Display
mounting
plate
Protection foam at the
front of the base
Front baffle
Protection foam on the
left and right of the
base
