Mindray A9 - Flowmeter Subsystem; EFCS Assembly

11-27
11.3 Flowmeter Subsystem
11.3.1 EFCS Assembly
No. Name P/N Test Item After
Replacement
Remarks
1
EFCS flowmeter flow sensor
051-002721-00
6.3.9 Total flow sensor
calibration
5.5 EFCS accuracy test
/
2
EFCS flowmeter monitoring
board FRU
115-077990-00
6.3.9 Total flow sensor
calibration test
5.5 EFCS accuracy test
5.6 BFCS function test
/
1
2
