Mindray A9 Service Manual

5-22
Vt 600
Rate 8
I:E 1:2
Tpause 10
PEEP Off
Plimit 50
7. Start ventilation.
8. Verify that the pressure waveform, respiratory volume, mean or plateau pressure, respiratory
rate, and minute ventilation appear on the screen.
9. Verify that the tidal volume displayed on the anesthesia machine is within 7% (±42 mL) of
the value displayed on the ventilation tester within approximately the first 1 minute after
ventilation starts.
10. Verify that the tidal volume displayed on the anesthesia machine is within 7% (±42 mL) of
the setting within approximately the first 1 minute after ventilation starts.
5.14.3 VCV Pediatric Ventilation Mode Test
1. Attach a breathing circuit and a manual bag.
NOTE
 For testing purposes, always use a reusable breathing circuit.
2. Attach an adult test lung to the Y-piece of the breathing circuit.
NOTE
 Limit the volume in the test lung to provide sufficient airway pressure to satisfy the
Low Peak Pressure alarm. Or set the peak pressure alarm limit to a smaller value
to prevent the alarm when an adult test lung is used.
3. Connect a ventilation tester between the expiratory port and the breathing hose.
4. Set the O2 flow to 2 L/min and set the N2O and air flows to the minimum value.
5. Set breathing parameters.
Parameter Setting
Patient Size Pediatric
Ventilation Mode VCV
Vt 120
Rate 15
I:E 1:2
Tpause 10
PEEP Off
Plimit 40
6. Start ventilation.

Mindray A9 Specifications

General

Type	Anesthesia Workstation
Integrated Gas Analysis	Yes
Backup Battery	Yes
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 55°C
Battery Type	Lithium-ion
Ventilation Modes	Volume Control, Pressure Control, SIMV, Manual Ventilation
Display	Touchscreen
Patient Monitoring	ECG, SpO2, NIBP, EtCO2, Temperature
Connectivity	Ethernet, USB
Portability	Mobile (with wheels)
Battery Life	Minimum 90 minutes (typical)
Altitude	Up to 3000 meters
Power Supply	100-240 VAC, 50/60 Hz
Charging Time	Approximately 4 hours
Storage	Internal storage for patient data and system logs
Supported Languages	Multiple languages
Certifications	CE, FDA
