11-17

11.1.13 Mechanical Vaporizer Subsystem (A8)

No. Name P/N Test Item After

Replacement

Remarks

1 Vaporizer manifold assembly (A8) 115-064121-00 5.8.1 Vaporizer interlock

assembly

5.8.4 Vaporizer leak test
