Mindray A9 Service Manual

11-16
No. Name P/N Test Item After
Replacement
Remarks
1
Airway pressure gauge
082-003308-00
5.2 System Check
/
2
Upper-left cover plate
FRU
115-066828-00
5.7.1 Vaporizer
Monitoring Function Test
The pressure
gauge is
removed from
the left cover
plate, and there
is no
auto/manual
switch.
3
Auto/manual switch
assembly
115-064076-00
5.2 System Check;
5.7.1 Vaporizer
Monitoring Function Test
/
4 I/O interface board 051-003189-00
Check whether the
network, USB, and DB9
ports are available.
/
5 O2 cell cable 009-009627-00
5.7.1 Vaporizer
Monitoring Function
Test
; Check whether the
O2 cell is properly
connected.
/
6
Work surface cover
plate FRU
115-066843-00
5.7.1 Vaporizer
Monitoring Function Test
Two waterproof
seals are
included.
7
Rubber plug for VE
door
049-001713-00 / /

Mindray A9 Specifications

General

Type	Anesthesia Workstation
Integrated Gas Analysis	Yes
Backup Battery	Yes
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 55°C
Battery Type	Lithium-ion
Ventilation Modes	Volume Control, Pressure Control, SIMV, Manual Ventilation
Display	Touchscreen
Patient Monitoring	ECG, SpO2, NIBP, EtCO2, Temperature
Connectivity	Ethernet, USB
Portability	Mobile (with wheels)
Battery Life	Minimum 90 minutes (typical)
Altitude	Up to 3000 meters
Power Supply	100-240 VAC, 50/60 Hz
Charging Time	Approximately 4 hours
Storage	Internal storage for patient data and system logs
Supported Languages	Multiple languages
Certifications	CE, FDA
