Mindray A9 Service Manual

4-2
7
13.2×1.8 O-ring, EPDM
rubber A70, white(A9)
4
Replace
Replace
082-003216-00
8
78×2.5 O-ring, silicon rubber
A50, colorless
1
Replace
Replace
082-003251-00
9
O-Ring 16X2 FKM A70
White
3
Check
Replace
082-003254-00
10
O-Ring 4.7x1.8 FKM A70
White
6
Check
Replace
082-003266-00
11
O-Ring 8.5X2 FKM A70
White
2
Check
Replace
082-003253-00
12
O-Ring 15.54X2.62 FKM
A70 White
2
Check
Replace
082-003284-00
13
O-Ring 23X2.5 FKM A70
White
2
Check
Replace
082-003244-00
14
Air Filter
（
Internal AG
）
1
Check
Replace
082-003616-00
/
O2 cell holder assembly
1
Check
Replace
115-064181-00
/
Flow sensor (resistant to
high-temperature disinfection)
1
Check
Replace
115-041519-00
/
Battery box assembly
1
Check
Replace
115-066846-0
/
Cell battery Lithium
3V35mAh
1
Check
Replace
M05-010R03---

Mindray A9 Specifications

General

Type	Anesthesia Workstation
Integrated Gas Analysis	Yes
Backup Battery	Yes
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 55°C
Battery Type	Lithium-ion
Ventilation Modes	Volume Control, Pressure Control, SIMV, Manual Ventilation
Display	Touchscreen
Patient Monitoring	ECG, SpO2, NIBP, EtCO2, Temperature
Connectivity	Ethernet, USB
Portability	Mobile (with wheels)
Battery Life	Minimum 90 minutes (typical)
Altitude	Up to 3000 meters
Power Supply	100-240 VAC, 50/60 Hz
Charging Time	Approximately 4 hours
Storage	Internal storage for patient data and system logs
Supported Languages	Multiple languages
Certifications	CE, FDA
