Mindray A9 Service Manual

7-53
Failure
Description
Cause Confirmation
Confirmation
Result
Solution
board and its cables (refer to
11.4.1).
The vaporizer
cannot be started.
Proceed with step 3 to
continue with the check.
3. After the vaporizer is
installed in place, select
Setup > Service > Data
Monitors > Status Monitor
to access the data
monitoring screen and check
the vaporizer status.
The vaporizer
status is ON.
Replace the electronic
vaporizer.
The vaporizer
status is OFF.
(1) Replace the electronic
vaporizer.
(2) Replace the electronic
vaporizer base interface
board and its cables (refer to
11.4.1).
(2) If the problem persists,
replace the monitoring and
controlling assembly (refer
to 11.1.11).
Vaporizer
activation failure
with successful
self-test
1. Check whether the gas
supply is sufficient.
The gas supply
pressure is less than
280 kPa (40 psi).
Connect or replace the gas
supply.
The gas supply
pressure is greater
than 280 kPa (40
psi).
Proceed with step 2.
2. Install the electronic
vaporizer in another slot and
try to activate it.
The vaporizer can
be activated.
Replace the electronic
vaporizer base interface
board and its cables (refer to
11.4.1).
The vaporizer
cannot be activated.
Proceed with step 3 to
continue with the check.
3. Without connecting the
vaporizer, set the drive gas
3-way valve to ON, observe
the status signal of the drive
gas 3-way valve on the left
the UI, and check whether
drive gas is output from the
manifold connector (refer to
4.6.6).
The status of the
drive gas 3-way
valve is ON, but no
drive gas is output.
Replace the vaporizer base
valve assembly (refer to
11.4.1).
The status of the
drive gas 3-way
valve is ON, and
drive gas is output.
Proceed with step 4.
The status of the
drive gas 3-way
valve is OFF.
Replace the vaporizer base
valve assembly (refer to
11.4.1).
4. Connect the vaporizer.
Check whether the value of
the pressure sensor is 0
when the drive gas 3-way
valve is set to OFF and is
within 150±5 kPa (22±0.7
psi) when the drive gas
3-way valve is set to ON
(refer to 3.6.6).
The value of the
pressure sensor is
within 150±5 kPa
(22±0.7 psi).
Replace the electronic
vaporizer.
The value of the
pressure sensor is
beyond 150±5 kPa
(22±0.7 psi).
Proceed with step 5.
5 Open the service door
(refer to 8.1.1) and measure
The output pressure
is within 150±5
Replace the electronic
vaporizer.

Mindray A9 Specifications

General

Type	Anesthesia Workstation
Integrated Gas Analysis	Yes
Backup Battery	Yes
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 55°C
Battery Type	Lithium-ion
Ventilation Modes	Volume Control, Pressure Control, SIMV, Manual Ventilation
Display	Touchscreen
Patient Monitoring	ECG, SpO2, NIBP, EtCO2, Temperature
Connectivity	Ethernet, USB
Portability	Mobile (with wheels)
Battery Life	Minimum 90 minutes (typical)
Altitude	Up to 3000 meters
Power Supply	100-240 VAC, 50/60 Hz
Charging Time	Approximately 4 hours
Storage	Internal storage for patient data and system logs
Supported Languages	Multiple languages
Certifications	CE, FDA
