Part Description
clockwise or counter clockwise.
A8: used to display the status of the gas supply pressure,
volume exchanger, electronic AGSS, and heating module
of the breathing system.
A9: used to display the status of the gas supply pressure,
volume exchanger, electronic AGSS, electronic
anesthetic vaporizer, and heating module of the breathing
backup flow control
The main flowmeter displays the total flow of the BFCS.
You can press the switch button to pen the BFCS control
door. The flow regulating knob can be used to control the
air and O2 flow. The gas flow increases when you rotate
the knob counterclockwise, and decreases when you
rotate the knob clockwise.
manifold
A8: used to install two Selectatec vaporizers. The
mounting bar supports two vaporizers. There is an
interlock mechanism inside the vaporizers, so that only
one vaporizer is used to deliver one anesthetic agent at a
time.
A9: used to install and lock electronic vaporizers (two
electronic vaporizers can be installed).
The indicator is on when the battery is being charged.
AC power status indicator
The indicator is on when the system is connected to AC
power.
The system switch is used to turn on or off the system.
The key and lock are used to lock the drawer.
Pipeline supply pressure
gauge
The gauge is used to indicate the pressure at the O2, air,
and N2O pipeline inlets.
cover
You can open the volume exchanger door cover by
pulling the unlock button at the bottom right outward as
The caster lock is a brake used to lock/release all casters
when you step on it.
The system is moved with the casters. The caster lock of
the machine is controlled by the central brake.
The humidifier must be connected to the pipeline when
you enable high-flow O2 supply.
