Mindray A9 Service Manual

11-7
No. Name P/N Test Item After
Replacement
Remarks
6
Display board
FRU of status
screen
115-077964-00(A9 US)
5.1 Power-on self-test;
5.7.1 Vaporizer Monitoring
Function Test
Upgrade the
software
package after
the
maintenance.
7
Small-display
service part
115-066860-00
5.1 Power-on self-test;
5.7.1 Vaporizer Monitoring
Function Test
/
8
Optical Encoder
24detent 5 VDC
Cable
010-000257-00
5.1 Power-on self-test. Verify
the functions of the rotary
encoder;
5.7.1 Vaporizer
Monitoring Function Test
The knob is
included.
9
Segment LCD,
I2C interface,
10-pin FPC
021-000481-00
5.7.1 Vaporizer Monitoring
Function Test; Turn on the
auxiliary O2/air module or
high-flow O2 therapy module
to check whether the segment
LCD is on.
/
10
BFCS keyboard
PCBA
051-002581-00
5.7.1 Vaporizer Monitoring
Function Test; Turn on the
auxiliary O2/air module or
high-flow O2 therapy module
to check whether the segment
LCD is on.
/

Mindray A9 Specifications

General

Type	Anesthesia Workstation
Integrated Gas Analysis	Yes
Backup Battery	Yes
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 55°C
Battery Type	Lithium-ion
Ventilation Modes	Volume Control, Pressure Control, SIMV, Manual Ventilation
Display	Touchscreen
Patient Monitoring	ECG, SpO2, NIBP, EtCO2, Temperature
Connectivity	Ethernet, USB
Portability	Mobile (with wheels)
Battery Life	Minimum 90 minutes (typical)
Altitude	Up to 3000 meters
Power Supply	100-240 VAC, 50/60 Hz
Charging Time	Approximately 4 hours
Storage	Internal storage for patient data and system logs
Supported Languages	Multiple languages
Certifications	CE, FDA
